Technical Data
| Condensate Treatment | Essiccatore a membrana | punto di rugiada -40°C |
|---|---|
| Particulate Treatment | 0,3 µm |
| Air purity class (ISO 8573-1) | 3-2-0 |
| Voltage (V) | 230 |
| Frequency (Hz) | 50 |
| Nominal rating (kW) | 2,80 |
| Nominal rating (HP) | 3,75 |
| Rotation speed (rpm) | 1.400,00 |
| Starting current (A) | 14,00 |
| Number of cylinders | 4 |
| FAD (L/min) | 320,00 |
| Air Delivery (L/min @5 bar) | 235,00 |
| Air Delivery (L/min @8 bar) | 180,00 |
| Maximum pressure (bar) | 10,00 |
| Noise level (3,00m @ 5,00 bar (dB(A)) | 72,00 |
| Duty cycle | S1 100% |
| Tank Coating | Acciaio Inox AISI 304 |
| Tank capacity (lt) | 90 |
| First Maintenance (hours) | 3000 |
| Hour Meter | Incluso |
| Tank Automatic Drain Valve | Optional |
Product dimensions
| Lenght (mm) | Width (mm) | Height (mm) | Weight (Kg) |
|---|---|---|---|
| 990,00 | 490,00 | 710,00 | 86,00 |
Single piece packaging dimensions
| Lenght (mm) | Width (mm) | Height (mm) | Weight (Kg) |
|---|---|---|---|
| 1100,00 | 600,00 | 900,00 | 105,00 |
Full pallet packaging dimensions
| Dimensions (mm) | Weight (Kg) | Pieces |
|---|---|---|
| - | - | - |
Air delivery
